ALINX AXKU15S: Xilinx Kintex UltraScale+ XCKU15P FPGA Development Board

Description FPGA Specification Features What's Included Resources & Downloads Description AXKU15S combines the 1.14M-cell XCKU15P with 5 GB of 80-bit DDR4 and direct access to PCIe Gen3 x16, dual QSFP28 and dual FMC HPC. A dense platform for high-throughput PCIe, optical networking, data acquisition and multi-interface FPGA development. The removable ACKU15S module separates the FPGA and memory subsystem from the carrier. 32 GTH plus 24 GTY transceivers, two SATA interfaces and two four-lane MIPI inputs support mixed storage, vision and communications designs on one board. FPGA Specification Kintex UltraScale+ KU15P System Logic Cells 1,143K CLB Flip-Flops 1,045K CLB LUTs 523K Distributed RAM 9.8 Mb Block RAM 34.6 Mb UltraRAM 36.0 Mb DSP Slices 1,968 Clock Management Tiles 11 Integrated IP and I/O PCIe Gen3 x16 Integrated Blocks 5 150G Interlaken Blocks 4 100G Ethernet Blocks with KR4 RS-FEC 4 Transceivers 32 GTH; 24 GTY User I/O 88 HD; 256 HP Device Part Number XCKU15P-2FFVE1517I Features FPGA Module System-on-Module ACKU15S, removable 80 × 80 mm module DDR4 5 GB, 80-bit QSPI Flash 2 × 64 MB Transceivers 32 GTH up to 16.3 Gb/s; 24 GTY up to 28.21 Gb/s High-Speed Interfaces PCI Express PCIe Gen3 x16 Optical 2 × QSFP28 FMC 2 × FMC HPC; FMC1: 58 LVDS pairs + 8 GTH; FMC2: 34 LVDS pairs + 8 GTH Camera 2 × four-lane MIPI Storage Interfaces 2 × SATA; microSD Peripheral and Mechanical Networking Gigabit Ethernet Control and Debug USB-UART; JTAG; 4 user keys; 4 user LEDs Monitoring LM75 temperature sensor; 512-byte 24LC04 EEPROM Power 12 V single supply Dimensions 226 × 111 mm What's Included ACKU15S system-on-module and AXKU15 carrier board Preinstalled FAN8060 heatsink and fan Mini USB cable USB programming cable 12 V power adapter PCIe bracket Resources & Downloads ALINX AXKU15S official product page AMD UltraScale+ FPGA Product Selection Guide
