Rotor-Stator: Position Control Torque Butt-Hinge

Features Torque position control hinge Range of motion (ROM): Full 270° rotation Free swing - The operational load is borne solely by the torque (friction-fit) mechanism throughout the hinge’s full 270° range of motion Rotary-static design (rotor-stator): Rotor - Rotating (moving) "hinge"/leaf component (door) Stator - Stationary (non-moving) "lid"/leaf component (enclosure) Torque specifications: Adjustable torque range ≤ 5 Nm (less than or equivalent to 5 Nm - approx.) Torque function: Symmetric Torque adjustment: Adjustable, friction-fit (via a Phillips head screwdriver) Operating temperature: -5℃ to 60℃ Easy installation: Front fixing holes Application: Suits both left hand and right hand install orientations Dimensions, Material & Finish Hinge body: Polyamide nylon, black Dynamic pin: Polycarbonate Base dimensions: 63.5mm (L) x 57mm (W) x 19mm (H) Mounting holes: Ø6.5mm (dia) x 4 (qty) Remarks Alternative sizes (mm), torque specifications (Nm), materials and/or finishes may be available upon request (subject to additional costs, MOQs and lead times) View Our Technical Datasheet
