NX102-9000

NX102-9000 NX102-9000 NX1 programable logic controller built-in EtherNet/IP™ up to 64 connections, EtherCAT® up to 0 synchronous axes Specifications NX102-9000 Controller functionality OPC-UA, Position control, Sequence control Max. number of synchronous axes 0 Max. number of PTP axes 4 Max. number of axes (incl. virtual) 4 Primary task cycle time 1 ms Program memory 5 MB Variables memory 33.5 MB Communication port(s) EtherCAT Master, EtherNet/IP, Ethernet TCP/IP Communication option(s) Serial RS-232C, Serial RS-422, Serial RS-485 Max. number of remote I/O nodes 64 I/O system NX I/O Bus Max. number of expansion units 32 Product Height (unpacked) 100 mm Product Width (unpacked) 66 mm Product Depth (unpacked) 100 mm Product Weight (unpacked) 470 g
