Borg Mini H7 Flight Controller - w/Rx

Introducing the All-New Borg Series – Power Meets Precision! The Borg Mini H7 Flight Controller is specifically designed for racing fpv, providing unmatched performance. Elevate your racing experience with the cutting-edge technology of the Borg Series! Features Supports 4S to 8S battery inputs, offering versatility for various racing setups. Integrated 12V BEC provides stable power for your VTX system and allows remote control to switch it on and off. FPC cables ensure secure connections with ESCs enhance reliability across. Onboard ELRS 2.4G receiver with external antenna, supports switching to external receivers. Onboard 4 LED strip interfaces with short-circuit protection, so an LED short circuit will not affect flight controller operation. Specifications Flight Controller Specifications Input voltage: 4-8S; Support LIHV battery MCU: STM32H743VIH6 Gyro: ICM42688 OSD Chip: AT7456E（LGA） Flash: 32MB (Blackbox flash) UARTS: 5 Motor outputs: 4 I2C serial: Support VTX protocol: support DJI MSP/Smartaudio/IRCTramp/HDZero LED controller: Yes Beeper pad: Yes Betaflight Firmware target: IFLIGHT_BORG_Mini_H7 Mount pattern: 20*20 φ4 Dimensions: 36*27mm±1 Weight: 7.7g±1 BEC: 5V 2.5A, 12V 2A (12V with VTX switch) Wiring Diagrams are available here. SMD Receiver Specifications MCU: ESP8285 RF: SX1281 Receiver Type: 2.4GHz Telemetry power: 100mW (20dBm) LNA: YES Lua Script: iFlight 2400 RX TCXO: Yes Firmware: iFlight2.4GHz_2400_RX Wiring Suggestion UART 1 for VTX HD / Analog UART 2 for ESC Telemet UART 4 for On-board Receiver UART 7 for GPS or other sensors that require a serial port UART 8 for GPS or other sensors that require a serial port Packing List 1 x Borg Mini H7 Flight Controller with SMD Receiver 1 x Cable set 1 x Antenna 5 x silicon grommets VTX_ON_OFF Mode Command resource PINIO 1 D10 set pinio_config = 1,1,1,1 set pinio_box = 40,41,255,255 set box_user_1_name = VTX_ON_OFF aux 0 40 8 900 2100 0 0 save
