Frigidaire Range Spark Module 5304505695, Replaces 08067972, 31600190001, 316135701, 316135702, 316T033P01, 5303207522, 5303209028, 5303280394, 7316135701, 7316135702, 8067972

GENUINE OEM REPLACEMENT PART 5304505695 Frigidaire 4-Output Spark Module for Ranges and Cooktops, Fixes Surface Burners Not Sparking Genuine Electrolux/Frigidaire four-output surface-burner spark module. Replaces 08067972, 316135701, 316135702, 316T033P01, 5303207522, 5303209028, 5303280394 and more. Part 5304505695 Replaces 08067972, 316135701, 316135702, 316T033P01, 5303207522, 5303209028, 5303280394, 7316135701, 7316135702, 8067972, 31600190001 4-Output Spark Module Frigidaire / Electrolux Range 5304505695 Frigidaire 4-Output Spark Module for Ranges and Cooktops, Fixes Surface Burners Not Sparking 🇺🇸 Matching U.S. Part Number: 5304505695 5304505695 is a genuine Electrolux/Frigidaire four-output surface-burner spark module. It replaces multiple discontinued Frigidaire ignition-module numbers including 08067972, 316135701, 316135702, 316T033P01, 5303207522, 5303209028, 5303280394, 7316135701, 7316135702, 8067972 and 31600190001 when fitment is confirmed by the appliance model number. The module receives signals from the burner ignition switches and generates high-voltage pulses for up to four surface-burner electrodes. A defective module may contribute to multiple burners producing no spark, weak or intermittent sparking, burners clicking without lighting or abnormal continuous clicking after controls are released. Is This the Right Part? Part Number5304505695 OEM DescriptionMODULE, SPARK, 4 OUTPUTS Replaces08067972, 31600190001, 316135701, 316135702, 316T033P01, 5303207522, 5303209028, 5303280394, 7316135701, 7316135702, 8067972 ManufacturerElectrolux / Frigidaire Appliance TypeRange / Cooktop Output Count4 outputs Confirm the complete appliance model and compare the original module’s output count, terminals and wiring arrangement before ordering. Similar modules may differ in output count, connector type or mounting configuration. Common Symptoms No spark at multiple surface burners Weak or intermittent spark at one or more burners Burners clicking without lighting Spark stopping when another burner is selected Continuous clicking after controls are released Check Before Replacing Inspect burner electrodes for cracks or carbon buildup — a damaged electrode can cause clicking without spark at that burner only Check for wet or dirty burner components — moisture is the most common cause of continuous clicking and can be resolved by drying the burner area Test the burner ignition switches — a failed switch may prevent the module from receiving a signal for that burner Inspect ignition wiring, connectors and grounding — a loose or damaged wire can produce the same symptoms as a failed module Pro Tip: If only one burner fails to spark, the fault is more likely a cracked electrode, damaged wiring or failed switch at that burner rather than the spark module. A defective module typically affects multiple burners simultaneously. Diagnose the full ignition circuit before ordering a replacement module. Part Details Part TypeSurface-Burner Spark Module — 4 Outputs Primary FunctionGenerates high-voltage ignition pulses for up to four surface-burner electrodes Key FeatureConfirm output count and wiring configuration match the original module ConditionGenuine OEM — New Installation Notes Disconnect electrical power and shut off the gas supply before servicing the ignition system. Photograph all wiring connections and electrode routing before removal. Compare the new module with the original — confirm output count, terminal positions and mounting before installation. Inspect burner electrodes, wiring harness and connectors for damage during the repair. Restore power and test all burner ignition positions after installation. Gas-appliance repairs should be completed by a qualified technician where required by local code. Verified Compatible Models CGCS389EB1, FGGC3045KBC, FFGC3015LSC Fitment reminder: Match the complete model number, including suffixes and revision digits, before ordering. Confirm the original module’s output count and wiring arrangement. ✓ Model-Specific Repair Pages Frigidaire FFGC3015LSC Ranges Parts & Repair Guide Frigidaire FGGC3045KBC Ranges Parts & Repair Guide Frigidaire CGCS389EB1 Ranges Parts & Repair Guide
