CTS 500k Audio Pot, S-1 Pushbutton Switch, Split Shaft

This is the pot behind Fender's S-1 switching system: a standard volume pot with a 4PDT switch built in, operated by pushing the knob. It's the way to add extra pickup combinations without drilling the guitar or adding a mini-toggle. Important: this pot only works with S-1 knobs. The switch is operated by a plunger in the center of the S-1 knob; a standard knob will turn the pot but can't work the switch. Add an S-1 volume knob in Parchment, Black or Aged White with the Knob option above (other knobs not included). Mounting hardware included (shown in the last photo). Specs 500k audio taper (logarithmic) Built-in 4PDT pushbutton switch (Fender S-1) Split shaft, 24 teeth (for push-on knobs) 3/8-32 SAE bushing thread 1/4" thread length (mount to pickguard or control plate) 15/16" body diameter
