Copeland White-Rodgers 066087 AAE 1SC-03, A-Series Thermostatic Expansion Valve, 3/8" x 1/2" ODF

Copeland White-Rodgers 066087 AAE 1SC-03, A-Series Thermostatic Expansion Valve, 3/8" x 1/2" ODF The A-Series is used for heat pump, air conditioning, food services and commercial applications. Features: Stainless steel power element eliminates corrosion and prevents valve failure Hermetic, leak-free construction Compact size allows installation in limited spaces Mass spectrometer tested to ensure less than 0.10 oz/year external leakage rate Specifications: Bleed: No Body Material: Brass Body Style: Straight Thru Capacity, Nominal [Ton]: 4.00 Capillary Length [in]: 60 Capillary Tube Length: 5 ft. Charge Code: C (Medium Temp) Equalizer: External Family: A-Series Thermostatic Expansion Valves Inlet Connection: 3/8" ODF Internal Check: No Maximum Working Pressure MWP [psig]: 700 Model Number: AAE 1SC-03 Outlet Connection: 1/2" ODF Refrigerant Code: S (R-404A, R-502, R-507) Superheat: Adjustable Superheat Setting: 6A UL/CUL File Number: SA5312 Capacity Table Instructions
