Pioneer SX-780

The Pioneer SX-780 is a highly popular vintage stereo receiver manufactured between 1978 and 1980, famous for its distinct silver face and wood-grain cabinet. Key Specifications Power Output: 45 watts per channel into 8 ohms Total Harmonic Distortion (THD): 0.05% Frequency Response: 5Hz to 80,000Hz Damping Factor: 30 Input Sensitivity: 2.5mV (Phono), 150mV (Line) Signal to Noise Ratio: 76dB (Phono), 95dB (Line) Output: 150mV (Line) Speaker Load Impedance: 4 ohms to 16 ohms Dimensions: 480 x 140 x 320 mm (18.9 x 5.5 x 12.6 inches) Weight: 11.2 kg (24.7 lbs) [1, 2, 3, 4, 5] Key Features Two large analog power meters Two analog tuning meters (Signal / Tune) Dual tape deck monitor loops Built-in Darlington power packs (STK-0050) [1, 2, 3, 4]
