Chief TC3 2.5" Bore 3,000 PSI Tie-Rod Hydraulic Cylinders

Chief TC3 2.5" Bore 3,000 PSI Tie-Rod Hydraulic CylindersSelect a Chief TC3 hydraulic cylinder by its bore, stroke, rod diameter and mounting style. Each model below is identified by its Primary Mover PFC number.Specifications Brand Chief Series TC3 Bore 2.5 in Rated pressure 3,000 PSI Construction Tie Rod Mounting style Clevis Models and dimensionsDimensions are in inches. Select the required stroke and configuration, then confirm the PFC model and rod size in the table. Model Stroke Rod diameter Configuration PFC-211320 4 in 1.125 in Standard - 1.125" Rod PFC-211321 6 in 1.125 in Standard - 1.125" Rod PFC-211322 8 in 1.125 in Standard - 1.125" Rod PFC-211323 8 in 1.125 in ASAE - 1.125" Rod PFC-211324 10 in 1.125 in Standard - 1.125" Rod PFC-211325 12 in 1.125 in Standard - 1.125" Rod PFC-211326 14 in 1.25 in Standard - 1.25" Rod PFC-211327 16 in 1.25 in Standard - 1.25" Rod PFC-211328 18 in 1.25 in Standard - 1.25" Rod PFC-211329 20 in 1.25 in Standard - 1.25" Rod PFC-211331 24 in 1.25 in Standard - 1.25" Rod PFC-211333 28 in 1.25 in Standard - 1.25" Rod PFC-211334 30 in 1.25 in Standard - 1.25" Rod PFC-211335 32 in 1.25 in Standard - 1.25" Rod PFC-211337 36 in 1.25 in Standard - 1.25" Rod PFC-211338 48 in 1.25 in Standard - 1.25" Rod Confirm pin dimensions, port size and retracted length against your application before selecting a replacement. Product images represent the cylinder family.For help matching a cylinder, contact Primary Mover support.
