Z8116AX-DS | Mini 5G WiFi 6 CPE Router MT7981B · 2975Mbps · Dual SIM · USB-C · Gigabit

Enterprise-Grade 5G WiFi 6 Router for Reliable Wireless Connectivity The Z8116AX-DS is a compact yet powerful 5G router built on the MT7981B ARM Cortex-A53 dual-core platform. Designed for demanding environments, it delivers blazing-fast WiFi 6 speeds with dual-band coverage and dual SIM failover — ideal for business, industrial, and home office deployments. Key Features WiFi 6 (802.11ax) — Total wireless throughput up to 2975 Mbps (573 Mbps @ 2.4GHz + 2402 Mbps @ 5.8GHz) 5G Ready — Supports 5G NR with dual self-ejecting SIM slots (SIM/USIM) Gigabit Ports — 1× WAN + 1× LAN, both at 1000Mbps for wired backbone connectivity Compact & Portable — Lightweight form factor suitable for fixed and mobile deployments Specifications Parameter Details Model Z8116AX-DS CPU MT7981B ARM Cortex-A53 Dual Core, 1.3GHz; WiFi Chipset MT7976CN Protocol IEEE 802.11n/g/b/a/ac/ax Wi-Fi Rate (2.4GHz) MAX 573 Mbps Wi-Fi Rate (5.8GHz) MAX 2402 Mbps Total Wi-Fi Rate 2975 Mbps FLASH/RAM DDR4 1GB RAM / SPI NAND Flash 128MB WAN Port 1× 1000Mbps LAN Port 1× 1000Mbps Power Port 1× TYPE-C (5V/3A, 9V/2A, 12V/1.5A) Buttons 1× Reset, 1× FN SIM Card Slot 2× Self-ejecting (SIM/USIM) Antenna 2× Omnidirectional 2.4G/5.8G Dual-Band + 4× Omnidirectional 5G 5G Standard X62
