Wall Mounted Freezer

Top Cabinet Model: AHE1450TCF Dimensions and Capacity Product Dimensions (W × D × H): 1450 × 590 × 1022 mm Internal Dimensions (W × D × H): 1330 × 390 × 645 mm Gross Volume: 373 L Net Volume: 232 L Shelves: 4 white metal shelves with 16 mm wire spacing Operating Environment Climatic Class: 3 Maximum Altitude: ≤1500 m Rated Voltage / Frequency: 220 V / 50 Hz Power Plug / Cord Length: UK plug / 2 m Certifications: CB, CE, ERP, RoHS and REACH Door and Cabinet Canopy: Flat metal canopy with light cover, painted black Door Frame: Extruded aluminium frame with plastic core, finished in black Number of Doors / Opening Style: 2 rotating doors Door Glass: 25 mm triple-layer glass, 4 + 3 + 4 mm, D-tempered with electric anti-condensation heater Door Opening Direction: Side to side, starting from the left Self-Closing Doors: Yes Door Lock: Standard round lock located on the grille Door Handle: Integrated extruded aluminium handle, finished in black Front Grille: Flat painted metal grille, finished in black Cabinet Exterior: Black pre-coated steel Display and Lighting Display Area: 0.74 m² Price Bar: 38 mm high, black, without cover Refrigeration System Foaming Agent: Cyclopentane Refrigerant / Charge: R290 / 80 g Temperature Range: −22 to −18°C Cooling System: Frost-free Condenser: 1 metal wire-and-tube condenser Condenser Fan: 1 standard fan, 29 W, 1300 RPM Condenser Airflow Direction: Towards the back Evaporator: 1 copper evaporator with fins Evaporator Fans: 2 square fans, 22 W each, 2200 RPM Cooling Switch: Yes Mechanical Thermometer: No Defrost Water Disposal: Self-evaporation Compressor: Standard fixed-speed compressor Noise Level: 62 dB Electrical and Energy Details Temperature Control: Electronic thermostat Controller Position: On the canopy Energy Standards: EU 2019/2018 and EU 2019/2024 Energy Class: E Daily Energy Consumption: 14.43 kWh per 24 hours Input Power: 650 W Rated Current: 4.7 A Defrost Type: Hot gas Defrost Power: 741 W Packaging and Logistics Package Dimensions (W × D × H): 1540 × 660 × 1155 mm Net Weight: 139 kg Gross Weight: 149 kg Number of Feet: 4 Bottom Cabinet Model Information Model: ZCD-L145S-S4T Operating Environment Protection Against Electric Shock: Class I Climatic Class: 3 Environmental Temperature / Humidity: 25°C / 60% RH Maximum Altitude: ≤1500 m Ingress Protection: N/A Rated Voltage / Frequency: 220 V / 50 Hz Power Plug / Cord Length: UK plug / 2 m Certifications: CB, CE, ERP, RoHS and REACH Cabinet Construction Cabinet Exterior: Black pre-coated steel Cabinet Interior: Black embossed aluminium Cabinet Frame: Left and right sections made from black injection-moulded ABS; front and rear sections made from grey extruded PVC and PMMA Cabinet Frame Heater: 18.1 W heating cable Sliding Bars: Black pre-coated nylon Glass and Window Window Frame: Left and right sections made from grey injection-moulded ABS; front and rear sections made from grey extruded PVC and PMMA Window Glass: 25 mm triple-layer glass with three 3 mm S-tempered panels and two Low-E coatings Middle Beam: Black injection-moulded ABS Middle-Beam Sliding Bar: Black pre-coated nylon Middle-Beam Insulation: Black EPDM sponge Middle-Beam Heater: 10 W heating cable Anti-Collision Protection Anti-Collision Strip Base: Grey extruded rigid PVC Anti-Collision Strip: Grey extruded flexible PVC Side Covers: Black injection-moulded ABS Front Glass and Handle Front Glass: Single-layer 4 mm S-tempered glass with Low-E coating Front Sliding Bar: Black extruded POM Sealing Strip: Brown wool sealing strip Insulation: Black EPDM sponge Handle: Black injection-moulded ABS Drainage System Internal Drain Channel: Straight sections made from black extruded rigid PVC; corner sections made from black injection-moulded ABS Drain Pipe: Black extruded rigid PVC Drainage Heater: 131 W heating cable Internal Parts Baskets: Grey dipped steel wire Dimensions and Capacity Product Dimensions (W × D × H): 1454 × 850 × 1080 mm Internal Dimensions (W × D × H): 1303 × 691 × 733 mm Gross Volume: 575 L Net Volume: 402 L Separator Grilles / Baskets: Bottom grille A: 30; bottom grille: 37 Display and Lighting Display Area: 0.75 m² Internal Lighting: P-type LED, 10 W + 14 W, 9000–10000 K Ambient Lighting: N/A Price Bar: Black PC sticker Refrigeration System Refrigerant / Charge: R290 / 105 g Temperature Range: −22 to −15°C Cooling System: Direct cooling Cooling Switch: Yes, integrated into the controller Defrost Water Disposal: Self-evaporation Compressor: Standard fixed-speed compressor Noise Level: 60 dB Electrical and Energy Details Temperature Control: Electronic thermostat Controller Position: Bottom-right corner Energy Standards: EU 2019/2018 and EU 2019/2024 Energy Class: E Daily Energy Consumption: 8.22 kWh per 24 hours Input Power: 420 W Rated Current: 3 A Defrost Type: Hot gas Defrost Power: 727 W Packaging and Logistics Package Dimensions (W × D × H): 1554 × 994 × 1010 mm Net Weight: 101 kg Gross Weight: 138.5 kg Castors: Castors with and without locks
