Universal Harness for ADU5 and ADU7

The WHP Universal ADU Harness provides a simple plug-and-play foundation for installing an ECUMaster ADU5 or ADU7. With only a few required connections, this harness helps reduce wiring time while supporting common ADU accessories and expansion options. Key Features: Compatible with ECUMaster ADU5 and ADU7 Pre-terminated Page and Warning Clear button connections USB logging port connection USB-to-CAN connection GPS-to-CAN connection Vehicle/ECU CAN connection Auxiliary I/O connections through DTM12 connector Includes: WHP Universal ADU Harness DTM12 I/O connector kit DTM2 Vehicle/ECU CAN connector kit DT4 GPS-to-CAN connector kit 5A fuse holder kit 1x Yellow button 1x Green button Optional Accessory: Optional OBD-II Adapter available. Connects CAN-Hi and CAN-Lo to a standard OBD-II (OBD2) diagnostic connector. Installation Guide
