Nelson 9822 Drive Arm & Counterweight Repair Kit for SR100/SR150

Nelson 9822 Drive Arm & Counterweight Service Kit Service the drive arm and counterweight bearing assemblies on your Nelson SR100 or SR150 Big Gun sprinkler with the Nelson 9822 repair kit. This kit brings together replacement bearings, radial lip seals, O-rings, spacers, retaining rings and nuts, plus Lubriplate grease and a drive arm seal installation tool. When it's time to service your sprinkler, having these components together helps you prepare for disassembly and reassembly using Nelson's step-by-step instructions. Specifications & Compatibility Manufacturer: Nelson Irrigation Kit number: 9822 Fits: Nelson SR100 and SR150 Big Gun sprinklers Service area: Drive arm and counterweight bearing assemblies Kit Contents 2 × 6563 O-rings, size -024 2 × 6565 retaining rings 3 × 6598 stainless steel ball bearings 4 × 6600 radial lip seals 2 × 6603 nuts 2 × 6607-001 cone spacers 1 × 8327-001 drive arm-to-counterweight spacer 1 × 9821 Lubriplate 130-AA grease, 1.75 oz. 1 × 13908 100/150 drive arm seal installation tool Before You Begin View Nelson 9822 service kit installation instructions (PDF) Need help confirming fit? Email customerservice@discountirrigation.com with your sprinkler model before ordering.
