ISDP 70 NSLK-K-BS di-soric Inductive Tube Sensor, Dynamic, NPN NO, M12 Pigtail

The di-soric ISDP 70 NSLK-K-BS is a dynamic inductive tube sensor for detecting metallic parts moving through supply tubes. The sensor mounts externally to the tube, allowing part detection without requiring the tube to pass through a closed sensing ring. This mounting arrangement allows the sensor to be installed or repositioned without dismantling the supply tube. The ISDP 70 NSLK-K-BS uses dynamic sensing with a 14 mm switching distance, NPN normally open output, and a short pigtail with M12 3-pin connection. Response/release time is 0.2 / 100 ms. Dynamic sensing provides a faster response to changes in the sensing condition and can be useful for faster part-detection and counting applications. Applications Typical applications include: metallic part detection in supply tubes part counting high-speed part detection accumulation monitoring feeder systems automated part handling assembly equipment packaging equipment production machinery Explore all di-soric Inductive Tube Sensors
