P Series 18 LED Side Emitting Module DC12V • 18 LEDs • IP20 • Professional Side-Emitting Solution for Double-Sided Light Boxes & Wayfinding Signs

P Series 18 LED Side Emitting Module DC12V • 18 LEDs • IP20 • Professional Side-Emitting Solution for Double-Sided Light Boxes & Wayfinding Signs Hero Banner Professional Side-Emitting LED Module for Slim Signage Designed for double-sided light boxes, wayfinding signage, and commercial illuminated displays, the P Series 18 LED Side Emitting Module delivers precise light distribution, excellent thermal performance, and stable brightness for demanding B2B signage projects. Perfect For Double-Sided Light Boxes Wayfinding & Directional Signs Airport & Metro Signage Shopping Mall Sign Systems Retail Displays Exhibition Light Boxes Commercial Advertising Signs Why Choose the P Series? Precision Side-Emitting Optical Design The side-emitting optical structure with a 15° × 45° beam angle directs light efficiently into slim sign cabinets, improving light uniformity while minimizing hotspots. Advantages Optimized side illumination Uniform light distribution Better performance in thin light boxes Professional lighting effect Reduced shadow areas High-Efficiency Optical Lens The premium PC optical lens maximizes light transmission while maintaining long-term durability. Benefits ✔ Higher light utilization ✔ Excellent impact resistance ✔ UV-resistant material ✔ Stable optical performance High Brightness 2835 LEDs Delivering approximately 140 lumens per LED, the module provides bright and efficient illumination suitable for commercial signage. Lighting Performance High luminous efficiency Stable color consistency Low heat generation Long operating life Product Features One LED, One Cut Each LED can be cut individually, allowing maximum flexibility when designing and assembling custom signage. Benefits Precise installation Less material waste Easier maintenance Faster production Dual-End Wiring Design The strip features wiring at both ends for quick installation and easy series connection. Advantages ✔ Faster installation ✔ Flexible wiring ✔ Supports serial connection ✔ Simplifies project assembly 1mm Aluminum PCB The thick 1.0 mm aluminum PCB offers excellent heat dissipation, improving product stability and extending service life. Thermal Benefits Better heat transfer Stable brightness Longer lifespan Improved reliability Technical Specifications Item Specification Product Series P Series Product Name P Series 18 LED Side Emitting Module LED Quantity 18 LEDs LED Type SMD 2835 Light Direction Side Emitting Voltage DC12V Waterproof Rating IP20 Beam Angle 15° × 45° Lens Material PC Optical Lens Color Temperature 13000K Color Rendering Index Ra ≥ 80 Brightness 140 lm / LED PCB Thickness 1.0 mm Aluminum PCB Power 1.2W / LED • 22W / Strip Product Size 990 × 25 × 1 mm Wiring Dual-End Wiring, Series Connection Polarity Blue (+), White (-) Warranty 2 Years Certifications CE, RoHS Key Advantages Professional Optical Performance Specialized side-emitting design for thin illuminated signs. Excellent Heat Dissipation 1 mm aluminum PCB improves thermal conductivity and product lifespan. Flexible Installation One LED per cut and dual-end wiring simplify installation for custom projects. Reliable Quality Manufactured under strict quality control with CE and RoHS compliance. Recommended Applications Double-Sided Light Boxes Uniform illumination for advertising and promotional displays. Wayfinding Systems Ideal for airports, hospitals, shopping malls, office buildings, and transportation hubs. Commercial Signage Suitable for retail stores, supermarkets, restaurants, and corporate branding. Exhibition Displays Provides clean and consistent lighting for trade show booths and display systems. Product Advantages for Sign Manufacturers Feature Customer Benefit Side-Emitting Design Better illumination in slim signs 15° × 45° Beam Angle More efficient light distribution One LED Per Cut Greater design flexibility Dual-End Wiring Faster installation 1 mm Aluminum PCB Superior heat dissipation CE & RoHS Certified Meets international market requirements 2-Year Warranty Lower maintenance costs OEM & ODM Services We provide comprehensive customization services: OEM Manufacturing Private Label Branding Custom Wire Length Custom Color Temperature Custom Packaging Bulk Wholesale Programs Project-Based Production Technical Support Packaging Information Item Specification Packaging 1 Strip / String Quantity per Carton 200 Strips Carton Size 106 × 26 × 20 cm Gross Weight 28 kg Quality Assurance Every module undergoes: 100% Functional Testing Brightness Consistency Inspection Electrical Safety Testing Aging Test Before Shipment Final Quality Inspection Frequently Asked Questions Q1: What applications is this module designed for? It is specifically designed for double-sided light boxes, wayfinding systems, and slim commercial signage. Q2: Can the module be cut? Yes. The one-LED-per-cut design allows flexible customization for different sign sizes. Q3: What material is used for the lens? A high-transmittance PC optical lens is used to maximize light efficiency and durability. Q4: Does it support series connection? Yes. The dual-end wiring design allows convenient series connection for large installations. Q5: Is OEM service available? Yes. We offer OEM/ODM manufacturing, customized packaging, branding, and technical support for distributors and sign manufacturers. Request a Wholesale Quote Factory-Direct LED Module Manufacturer Whether you are a sign manufacturer, lighting distributor, advertising contractor, or OEM brand, the P Series 18 LED Side Emitting Module provides a reliable, energy-efficient, and professional lighting solution for modern illuminated signage. Why Partner with JHG? ✔ Factory Direct Pricing ✔ Stable Product Quality ✔ Fast Production & Delivery ✔ CE & RoHS Certified ✔ OEM & ODM Services ✔ Global Wholesale Support Contact us today for samples, technical datasheets, and distributor pricing.
