OAK 4 CS OG05B10 (Global Shutter)

The OAK 4 CS (OG05B10, Global Shutter) is Luxonis' standalone edge-inference camera built for flexible, precision imaging of fast-moving subjects. Its single-lens CS-mount supports interchangeable optics, pairing a global-shutter sensor with on-device AI and computer vision on the RVC4 platform. Key highlights RVC4 compute — 6-core ARM CPU (Qualcomm Snapdragon 8-series), 8GB RAM, 128GB storage, running Luxonis OS on Linux kernel 5.15. 52 TOPS AI — 48 TOPS (INT8) DSP plus 4 TOPS (FP16) GPU for on-device inferencing. OG05B10 sensor — up to 5MP (2592×1944), global shutter, up to 90 FPS, 2.2µm pixel size — ideal for fast motion without rolling-shutter artifacts. Interchangeable CS-mount optics for tailoring field of view to the application. Built-in microphone and 9-axis IMU. Rugged housing — industrial aluminium with front Gorilla Glass, IP65 rated (IP67 with lens hood attached). Flexible connectivity — 2.5GbE PoE (802.3at Class 4, M12) or USB-C (USB 3.2 Gen2, 10 Gbps), usable together, plus an M8 IO connector. Physical specifications Dimensions: 58.2 × 58.2 × 72 mm (without lens); 58.2 × 58.2 × 132 mm with stock CS lens attached Weight: 325g (without lens); 425g (with stock CS lens) Mounts: 1/4" tripod mount; 50mm M4 VESA mounts on back and bottom Operating temperature: −20°C to 40°C In the box 1× OAK 4 CS · 1× M12/RJ45 connector. Why buy from MG Super Labs Stocked and shipped within India · Prices in INR (no import duties or customs delays) · GST invoice with every purchase · Warranty as per manufacturer terms · Local technical support for OAK & DepthAI.
