Wago 750-333 Fieldbus Coupler

- Brand: WAGO - Model: Fieldbus Coupler PROFIBUS DP (2nd Generation, 12 MBd) - Type: Fieldbus Coupler / Communication Module - Part Number: 750-333 - Technical Specs: - Communication Protocol: PROFIBUS DP / DP/V1 - Transmission Rate: 9.6 kBd to 12 MBd - Maximum Bus Segment Length: 1200 m - Max Number of Modules per Node: 63 - Input / Output Process Image: Max. 244 Bytes / 244 Bytes - Supply Voltage (System & Field): 24 VDC (-25% to +30%) - Current Consumption (5V System Supply): 200 mA - Total Current (System Supply): 1800 mA - Connection Technology: 1 x D-Sub 9 socket (PROFIBUS), CAGE CLAMP® (System/Field supply) - Mounting Type: DIN-35 Rail - Operating Temperature: 0°C to +55°C - Protection Rating: IP20 Weight: 190 g Dimensions: 100 x 50 x 75 mm Country of Origin: Germany HS Code: 8517.62.00
