Triplex RTD Sensor With 4-20mA Transmitter

Parameter Specification Type PT-100 Make Aavad Model APFT-TT-6×3250 Configuration Triplex No. of wire 3+3+3 = 9 Wire Accuracy Class A Temperature range -50 To 400℃ Material of construction SS 316L Insulation Compacted MgO insulation Protection head Die-Cast aluminum flameproof head with threaded cap & chain Head protection class IP-65 Head cable entry connection 1/2″ NPT (F) No. of cable entry 4 Way Terminal block Nickel-plated ceramic terminal block Od 6 mm Length below head 3250 mm Transmitter Head-mounted transmitter Setting Zero-Span adjustable Input RTD Power supply 24V DC Output 4-20 mA, 2-wire (Single output) Calibration range -50 To 400℃ View More Details
