VESTWOODS VES1100L 51.2V 100Ah LiFePO4 Battery (5.12kWh) – Floor Mounted Solar Energy Storage with CAN/RS485

The VES1100L 51.2V 100Ah LiFePO4 (LFP) Lithium Battery is a high-performance 5.12kWh solar energy storage solution designed for home backup power, hybrid solar systems, and off-grid applications. Built with safe and long-lasting Lithium Iron Phosphate cells, the VES1100L delivers consistent power, excellent efficiency, and a long service life for daily cycling. With an operating voltage range of 42.0V to 57.6V, 100A max continuous charge/discharge, and a recommended 80% depth of discharge, this battery is engineered for reliable performance in real-world conditions. It supports CAN and RS485 communication for smart inverter integration and monitoring, and features natural cooling for quiet, maintenance-friendly operation. The VES1100L is also expandable—connect up to 15 units in parallel to increase storage capacity as your energy needs grow. With full protection features (overcharge, over-discharge, over-temperature, over-current, short circuit, and more) and certifications including UN38.3, IEC62619, CE-EMC, and RoHS, it’s a dependable and compliant choice for modern solar storage systems. Key Specifications (VES1100L) Model: VES1100L Battery Type: LiFePO4 (LFP) Nominal Energy: 5.12kWh Nominal Capacity: 100Ah Nominal Voltage: 51.2V Operating Voltage Range: 42.0–57.6V Nominal Charge Voltage: 57.6V Max Continuous Charge Current: 100A Max Continuous Discharge Current: 100A Discharge Cut-off Voltage: 42.0V Recommended DOD: 80% Cycle Life: 6000 cycles @ 80% DOD @ 25°C Design Life: 15+ years (25°C) Communication: CAN / RS485 Expansion: Up to 15 units in parallel Installation: Floor Mounted Cooling: Natural Cooling IP Rating: IP20 Dimensions (W×H×D): 420 × 700 × 150 mm Weight: Approx. 45 kg Charge Temperature: 0–60°C Discharge Temperature: -20–60°C Humidity: ≤95% RH | Altitude: <2000m Compatible Inverters: Deye, Solis, Hoymiles, Senergy, Afore, Megarevo, SRNE, Inhenergy, etc. Certifications: UN38.3, IEC62619, CE-EMC, RoHS
