Lunatone wDALI-2 Bluetooth 5 CW-WW LED Dimmer CC DT8

Lunatone wDALI-2 CW-WW Dimmer module is used to wirelessly control tuneable white luminaries via one DALI address (DALI DT8). The LED ballasts can be switched, dimmed and adjusted in colour temperature by using DALI commands. The device supports Operating Mode DT8, Operating Mode Balance&Dim, Operating Mode Dim2Warm. Wireless control is achieved through a transmitter unit wDALI-2 BT5 Bridge and the receiver module wDALI-2 CW-WW Dimmer. The transmitter is connected to the DALI line, while the receiver is powered by 12-48V DC. The wireless range depends on structural conditions: 8–12m (up to 150 m in open field). Specifications Technical data Ambient temperature -20°C to +60°C Protection class IP20/IP40 Connection wire cross section max. 1.5mm² Mounting Back box / Installation box Electrical data Input V+, V- (GND) Input type Supply, DC: V+, V- Supply voltage Vin 12V DC … 48V DC (SELV) Max. output current Iled 350mA Rated power @12V / @48V 4.2W / 16.8W Standby power consumption ~ 180mW @12V Power on behaviour configurable via DALI: 0%-100% or last actual level Output: LED+, LED- Output type LED dimmer, constant current PWM: LED+,LED- Number of outputs 2 Output voltage range Vled 3V-45V (at 48V supply) Max. input current Iinmax 350mA Max. output power per channel @45V 15,75 W Function Device type wDALI system extension - wireless 2 Ch LED Dimmer Wireless technology / policy Bluetooth 5 Long Range Configurable with DALI Cockpit PC Software Yes Dimensions Length 59mm Width 33mm Height 15mm Colour Grey Downloads wDALI-2 BT5 CW-WW LED Dimmer CC DT8 Data Sheet wDALI-2 BT5 wireless DALI Bridge Data Sheet wDALI-2 BT5 wireless RM8 Data Sheet
