Victron Energy Orion-Tr 48/12-30A (360W) Isolated DC-DC Charger

The Orion-Tr Smart DC-DC charger is an adaptive 3-stage charger (bulk – absorption – float) designed for dual battery systems, such as in vehicles or on boats where the starter battery (hence the alternator) is used to charge the service battery. The name "Smart" comes from its built-in Bluetooth connection, where the charger can be monitored and configured via Bluetooth and can be remotely controlled via a remote on/off switch and has an engine running detection mechanism. This isolated model allows the input and output to have separate chassis grounds. The Orion-Tr Smart charger can be used in 12V, 24V or 48V systems and is suitable for both lead acid and lithium batteries. Models are available up to 400W and unlimited multiple units can be connected in parallel to increase output power. Suitable for high temperatures up to 55°C with a full rated output up to 40°C. Input Voltage Range 32-70V Under voltage shut down 28V Under voltage restart 30V Nominal output voltage 12.2V Output voltage adjust range 12.2V Output voltage tolerance 10-15V Output voltage tolerance +/- 0.2V Output noise 2 mV rms Cont. output current at nominal output voltage and 40°C 30A Maximum output current (10s) at nominal output voltage minus 20% 40A Short circuit output clinic 60A Cont output power at 25°C 430W Cont output power at 40°C 360W Efficiency 87% No load input current <80mA Standby current Less than 1 mA Can be used as power supply Yes, output voltage can be set with Bluetooth Galvanic isolation 200 VDC between input, output and case Operating temperature range -20 to +55°C (derate 3% °C above 40°C) Humidity Max 95% non-condensing DC connection Screw terminals Maximum cable cross-section 16 mm2 (AWG6) Protection category IP43 (electronic components) IP22 (connection area) Standards: Safety Emission / Immunity Automotive Directive EN 60950 EN 61000-6-3, EN 55014-1 / EN 61000-6-1, EN 55014-2 ECE R10-5
