Sargent 8245 Mortise Lock, Lock Body Only, Dormitory or Exit Function, Single Cylinder with Deadbolt

Sargent 8245 Mortise Lock, Lock Body Only, Dormitory or Exit Function, Single Cylinder with Deadbolt, Grade 1, Field ReversibleThe Sargent 8245 Mortise Lock delivers dependable Grade 1 security for high-traffic commercial openings such as dormitories, apartments, and other applications requiring controlled entry with a positive deadbolt. This lock body-only configuration provides the dormitory or exit function with a single cylinder and deadbolt, allowing the outside to be locked or unlocked by key while permitting free egress from the inside. Built to meet ANSI/BHMA A156.13 standards and part of Sargent's proven 8200 Series, the 8245 is field reversible for installation flexibility and engineered for years of reliable service. It's an ideal solution for institutional and multi-residential facilities that demand durability and code compliance.Features Dormitory or exit function with single cylinder and deadbolt for secure, controlled access. Grade 1 rated construction built for demanding commercial and institutional environments. Field reversible design simplifies handing during installation. Lock body only, allowing you to pair with your preferred trim, cylinders, and finish. Part of the durable Sargent 8200 Series mortise lock platform. Functional DetailsThe 8245 dormitory/exit function allows the outside lever or knob to be locked and unlocked by key, while the deadbolt is thrown and retracted by key from the outside or by turn unit from the inside. Rotating the inside lever retracts both the latchbolt and deadbolt simultaneously for immediate free egress at all times. Deadbolt thrown or retracted by key outside or thumbturn inside. Latchbolt operated by lever from either side except when outside is locked by key. Inside lever always free for immediate egress, retracting both latchbolt and deadbolt. Included ComponentsThis model ships as a lock body only. Cylinders, trim, roses, levers or knobs, and strikes are ordered separately to match your specification and finish requirements.Product Specifications Manufacturer Sargent SKU 8245 Series 8200 Mortise Lock Series Function Dormitory or Exit, Single Cylinder with Deadbolt Configuration Lock Body Only Grade Grade 1 ANSI Number ANSI/BHMA A156.13 Handing Field Reversible Origin Made in USA Unit of Measure Each BAA Qualified Yes Limited Warranty Yes Technical Specifications Lock Type Mortise Lock Backset 2-3/4" Case Depth 4-3/4" Case Height 6" Case Thickness 15/16" Latchbolt Throw 3/4" Deadbolt Throw 1" Faceplate 1-1/4" x 8" armored front, beveled Door Thickness 1-3/4" standard Cylinder Type Standard mortise cylinder (single) Latchbolt Material Stainless steel
