Lifemeta™ STT Platinum-cured Silicone Tubing ID 0.8mm ~ 4.8mm, Length: 50 Ft or 15 m
Physical Properties Product Name Lifemeta™ STT Platinum Cured Silicone Tubing Color Translucent Tube Length 15 m Tube Type Coils Durometer Hardness (Shore A) 60 ± 5 Tensile Strength 7.05 - 8.96 MPa Elongation at Break 378 - 443% Materials Tubing Material Platinum-cured Silicone Operating Conditions Burst Strength 0.4 - 0.9 MPa Vacuum Resistance > 30 kPa Temperature Range -51 °C to 232 °C Regulatory Compliance Compliance USP <788> Particulate Matter USP <87> Cytotoxicity USP <88> Biological Reactivity ISO 10993-4 non-hemolytic FDA Indirect Food Additives, 21 CFR 177-182 ADCF Materials Bacterial Endotoxin Endotoxin Limit of WFI System<0.25 EU/mL with the Limulus Amebocyte Lysate (LAL), USP <85> Sterility Delivery Condition Non-sterile Sterilization Method Can be sterilized by gamma Irradiation at 25-45 kGy or Can be autoclaved for 30 minutes at 121°C Package Pack Size Pack of 1 coil Packaging Individually packed in double PE bag
Specifications
- Tube Size (ID – OD)
- 1/32"(0.8mm) ID x 5/32"(4.0mm) OD x Wall 1.6mm (13#), 3/64"(1.2mm) ID x 11/64"(4.4mm) OD x Wall 1.6mm, 1/16"(1.6mm) ID x 3/16"(4.8mm) OD x Wall 1.6mm (14#), 1/16"(1.6mm) ID x 1/4"(6.4mm) OD x Wall 2.4mm (119#), 3/32"(2.4mm) ID x 7/32"(5.6mm) OD x Wall 1.6mm (19#), 3/32"(2.4mm) ID x 9/32"(7.1mm) OD x Wall 2.4mm, 3.0mm ID x 6.0mm OD x Wall 1.5mm, 1/8"(3.2mm) ID x 5/16"(8.0mm) OD x Wall 2.4mm (120#), 1/8"(3.2mm) ID x 1/4"(6.4mm) OD x Wall 1.6mm (16#), 3/16"(4.8mm) ID x 5/16"(8.0mm) OD x Wall 1.6mm (25#), 3/16"(4.8mm) ID x 3/8"(9.6mm) OD x Wall 2.4mm (15#), 3/16"(4.8mm) ID x 7/16"(11.2mm) OD x Wall 3.2mm
- Length
- 15 m
Variants (12)
- 1/32"(0.8mm) ID x 5/32"(4.0mm) OD x Wall 1.6mm (13#) / 15 m — 99.00 USD — In stock
- 3/64"(1.2mm) ID x 11/64"(4.4mm) OD x Wall 1.6mm / 15 m — 77.00 USD — In stock
- 1/16"(1.6mm) ID x 3/16"(4.8mm) OD x Wall 1.6mm (14#) / 15 m — 73.00 USD — In stock
- 1/16"(1.6mm) ID x 1/4"(6.4mm) OD x Wall 2.4mm (119#) / 15 m — 71.00 USD — In stock
- 3/32"(2.4mm) ID x 7/32"(5.6mm) OD x Wall 1.6mm (19#) / 15 m — 75.00 USD — In stock
- 3/32"(2.4mm) ID x 9/32"(7.1mm) OD x Wall 2.4mm / 15 m — 107.00 USD — In stock
- 3.0mm ID x 6.0mm OD x Wall 1.5mm / 15 m — 56.00 USD — In stock
- 1/8"(3.2mm) ID x 5/16"(8.0mm) OD x Wall 2.4mm (120#) / 15 m — 116.00 USD — In stock
- 1/8"(3.2mm) ID x 1/4"(6.4mm) OD x Wall 1.6mm (16#) / 15 m — 56.00 USD — In stock
- 3/16"(4.8mm) ID x 5/16"(8.0mm) OD x Wall 1.6mm (25#) / 15 m — 101.00 USD — In stock
- 3/16"(4.8mm) ID x 3/8"(9.6mm) OD x Wall 2.4mm (15#) / 15 m — 116.00 USD — In stock
- 3/16"(4.8mm) ID x 7/16"(11.2mm) OD x Wall 3.2mm / 15 m — 172.00 USD — In stock
