Standalone Access Control Keypad

This is a single door multifunction standalone access controller or a Wiegand output reader. It uses Atmel MCU assuring stable performance. The operation is very user friendly, and low-power circuit makes it long service life. Features Bluetooth module (optional), to connect mobile for opening doors Fashion design, all metal buttons Metal case, anti vandal Waterproof One relay, keyboard programmer 1000 users, 998 Common users and 2 Panic users PIN length: 4-6 digits EM version - 125KHz EM card, HID and EM version - 125KHz HID and EM cards Wiegand 26~37 bits input and output Can be used as a Wiegand reader with LED and buzzer output Card block enrolment Tri-colour LED status display Integrated alarm and buzzer output Pulse mode, Toggle mode User data can be transfered 2 devices can be interlocked for 2 doors Built in light dependent resistor (LDR) for anti tamper Backlit keypad Low temperature resistance (-40 degrees celsius) Voltage: 12~28V AC/DC Product code is XK1-EM
